Optional visuals companion

memory-atlas is the data plane: plain-markdown vaults, a zero-dependency CLI, and verifier invariants. A presentation plane over those vaults is optional and lives in a separate package.

Package	Role	Runtime deps	npm
`memory-atlas`	Vault layout, `atlas` CLI, check/build/stamp/wire	None (Node only)	memory-atlas
`memory-atlas-visuals`	Gallery app, digests, typeset/derived presentation	Heavy UI (React, Vite, etc.)	memory-atlas-visuals

Installing memory-atlas never pulls React, a bundler, or a gallery. The companion is opt-in, separately versioned, and never imported by the core package. Wire it when you want humans to read the vault as digests + diagrams — not when you only need atlas check.

Zero-dependency rule (load-bearing)

Core must not ship presentation UI. Config keys under atlas.config.json → visuals are declarative only: this package reads and merges them, documents paths, and may forward to a companion binary when present. It never requires / imports memory-atlas-visuals. Zero runtime dependencies on the core package stay intact.

Reserved `visuals/` tree

Name visuals/ is reserved under the vault (default retrieval.excludeFromSearch includes "visuals/"; loaders always skip a visuals directory).
Agents and search indexes omit it by default — presentation artifacts are not Map/Ledger corpus.
SPEC defines no digest or gallery contract; the companion owns its own versioning.

Content that belongs to the vault presentation tree (still outside agent search by default):

Path (vault-relative defaults)	Holds
`visuals/illustrated/`	Skinned digests (`.mdx` only — see Ouroboros)
`visuals/files/`	Binary / diagram assets (Excalidraw, stock heroes, …)
`visuals/visuals.config.json`	Companion config
`visuals/app/` (or package-owned app)	Gallery runtime — not Atlas source notes

Enable

Declare intent in atlas.config.json (keys default off — see CONFIG.md):
```
"visuals": { "enabled": true }
```
Install the companion as a dev dependency:
```
npm i -D memory-atlas-visuals
```
Scaffold the vault tree (writes under visuals/ when the companion CLI is available):
```
atlas visuals init --write
```
Wire on-ramp / hooks as usual (optional; does not load React into core):
```
atlas wire all
```

Run the gallery:

atlas-visuals dev
# or, when the core CLI forwards:
atlas visuals dev

Default local port is visuals.port (4555). Override in config if needed.

`concurrentDev`

When visuals.concurrentDev is true (default once keys are present), consumer dogfood/dev scripts may start the gallery alongside the product app. That concurrent start is the adopting repo’s responsibility — memory-atlas does not spawn product servers or couple to a framework. Core only exposes the flag so scripts and companions can agree.

Ouroboros rule

Presentation must not re-enter the Atlas corpus:

No .md under visuals/ that agents would treat as Map/Ledger notes.
Digests are .mdx only under illustrated/ (or the configured visuals.illustrated path).
The gallery app and its node_modules stay outside every Atlas generator, ownership glob, and retrieval index.

Violating this creates a self-referential loop (the display layer becomes “architecture memory”).

Three presentation tiers (brief)

The companion presents vault notes in three tiers. Coverage of digests is not a goal; most notes never leave the first two tiers.

Tier	What	Cost	Typical coverage
Typeset	Source markdown in a shared typeset stylesheet	One CSS surface	Every note
Derived	Deterministic chrome from frontmatter + headings (hero hook, metrics, tags, TOC)	Code only — zero LLM	Every note
Digest	Hand-authored editorial MDX (stock hero, diagram, synthesized cards, motion)	LLM session + review	The few notes that earn it

Typeset + Derived are the product floor for a stranger’s vault. Digests are earned per genre (often programs, load-bearing specs/decisions) — not a coverage KPI.

What stays in memory-atlas

Verifier, stamp, build, wire, adopt, migrate, search
visuals config shape + schema + defaults
Hard exclusion of visuals/ from note loading and default search

What lives only in memory-atlas-visuals

React/Vite gallery, skins, MDX kit
Digest authoring pipeline / skin skills
Diagram and stock asset tooling
